28mm Leg LED 3mm Dark Green (5pcs)

The 28mm Leg LED 3mm Dark Green comes in a pack of 5 small round LEDs that light up a deep green. Each LED has a 3 mm lens and long 28 mm legs, which leave plenty of length to reach a breadboard row, pass through a front panel or be trimmed after soldering. They are a neat choice for compact indicators where a 5 mm LED would be too large.

28mm Leg LED 3mm Dark Green Specifications

• LED size: 3 mm round lens
• Colour: dark green
• Leg length: 28 mm
• Mounting: through-hole, 2 legs (anode and cathode)
• Typical current: up to 20 mA
• Pack size: 5 pieces

28mm Leg LED 3mm Dark Green Applications

• Power-on and ready indicators on project boxes
• Battery and charging status lights
• GPIO exercises on Arduino, ESP32 and Raspberry Pi
• Model railways, dollhouses and small signal models
• STEM kits and classroom experiments

What's in the Box

• 5 × 3 mm dark green LEDs with 28 mm legs

Tip: Connect the long leg (anode) to the positive side and the short leg (cathode), usually marked by a flat edge on the rim, to ground. Always add a series resistor, 220 Ω to 330 Ω when running from 5 V, so the current stays within safe limits.
