4 x AA Battery Holder Box, Without Cover

The 4 x AA Battery Holder Box is an open battery holder, without a cover, that takes four AA cells connected in series. With alkaline batteries it supplies about 6 V, or about 4.8 V with rechargeable NiMH cells, which makes it a simple portable power source for robot cars, servos, toys and motor projects.

4 x AA Battery Holder Box Specifications

• Capacity: 4 × AA cells
• Connection: series
• Output voltage: about 6 V with alkaline cells (4 × 1.5 V), about 4.8 V with NiMH cells (4 × 1.2 V)
• Design: open frame, without cover
• Batteries: not included

4 x AA Battery Holder Box Applications

• Powering robot car chassis and small DC motors
• Supplying SG90 and MG90S servos, which run from 4.8 V to 6 V
• Toys, LED projects and science fair models
• Portable power for STEM and robotics classes

What's in the Box

• 1 × 4 × AA battery holder (batteries not included)

Tip: Check the polarity marks in each slot and insert the cells with the flat (negative) end against the spring. Fresh alkaline cells can give over 6 V in total, so do not connect the pack directly to the 5 V pin of an Arduino or to a 3.3 V board such as the ESP32; use a regulator instead.
