6 Pin Female 11mm tall stackable Header Connector (5 per pack)

The 6 Pin Female 11mm tall stackable Header Connector pack contains 5 single-row female headers with 6 contacts each and long straight pins. Stackable headers let you build shields and add-on boards that plug into an Arduino or another board while keeping a female socket on top, so you can stack more boards or plug jumper wires in above.

6 Pin Female 11mm tall stackable Header Specifications

• Contacts: 6, single row
• Style: female socket on top, long straight pins below
• Height: 11 mm tall (as listed)
• Pitch: 2.54 mm (0.1 in)
• Mounting: through-hole, solder
• Pack size: 5 pieces

6 Pin Female 11mm tall stackable Header Applications

• Arduino Uno shields: the 6-pin size matches the A0–A5 analog header
• Stackable add-on boards and custom shields
• Modules that need pins below and sockets above
• Perfboard prototypes that plug into another board

What's in the Box

• 5 × 6-pin stackable female headers

Tip: Solder the header from the bottom of your board with the long pins pointing down, and keep it straight by plugging it into the board below while you solder. A full Uno R3 shield also needs 8-pin and 10-pin headers, so check the counts your design needs.
