8 Pin Female 11mm tall stackable Header Connector (5/Pack)

The 8 Pin Female 11mm tall stackable Header Connector pack contains 5 single-row female headers with 8 contacts each and long straight pins that pass through the board. Solder one to a shield or perfboard and you get a female socket on top and male pins underneath, so your board can plug into an Arduino and still let you stack another board or plug jumper wires in above.

8 Pin Female 11mm tall stackable Header Specifications

• Contacts: 8, single row
• Style: female socket on top, long straight pins below (stackable)
• Height: 11 mm tall (as listed)
• Pitch: 2.54 mm (0.1 in)
• Mounting: through-hole, solder
• Pack size: 5 pieces

8 Pin Female 11mm tall stackable Header Applications

• Arduino Uno shields: the 8-pin size matches the D0–D7 digital header and the power header
• Stackable add-on boards and custom shields
• Removable sockets for modules on perfboard
• Raising a board to clear tall components

What's in the Box

• 5 × 8-pin stackable female headers

Tip: To keep the headers straight while soldering, plug them into the board they will stack onto, place your shield on top and solder from above. Do not trim the long pins, as they plug into the board below. A full Uno R3 shield uses two 8-pin headers, one 10-pin and one 6-pin header.
