DC Motor 12GA 3V 110rpm

The DC Motor 12GA 3V 110rpm is a compact DC gear motor in the 12GA size, rated for 3 V, with a gearbox output speed of 110 rpm, almost 2 turns per second. It runs from two AA cells and gives a useful middle speed for small robot cars, arms and moving models where a 6 V or 12 V battery pack would be too bulky.

DC Motor 12GA 3V 110rpm Specifications

• Model: 12GA
• Type: DC gear motor (motor with reduction gearbox)
• Rated voltage: 3 V DC
• Output speed: 110 rpm at 3 V (about 1.8 turns per second)
• Suggested supply: 2 × AA or AAA cells (about 3 V)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 12GA 3V 110rpm Applications

• Small two-wheel robots and line followers
• Robot arms and grippers
• Battery-powered toys and models
• STEM classes and science fairs

What's in the Box

• 1 × DC Motor 12GA 3V 110rpm

Tip: Power the motor from 2 × AA cells or a separate 3 V supply, not from the 3.3 V pin of an ESP32 board, whose regulator is not meant for motor current. A DRV8833 or L9110S driver works well at this low voltage.
