DC Motor 12GA 3V 30rpm

The DC Motor 12GA 3V 30rpm is a compact DC gear motor in the 12GA size, rated for 3 V, with an output speed of 30 rpm, which is one full turn every 2 seconds. The high gear reduction gives slow, deliberate motion and plenty of torque for its size, all from a simple two-cell battery pack.

DC Motor 12GA 3V 30rpm Specifications

• Model: 12GA
• Type: DC gear motor (motor with reduction gearbox)
• Rated voltage: 3 V DC
• Output speed: 30 rpm at 3 V (1 turn every 2 seconds)
• Suggested supply: 2 × AA or AAA cells (about 3 V)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 12GA 3V 30rpm Applications

• Automatic feeders and dispensers
• Turntables and rotating displays
• Small winches and lifts in models
• Sun-tracking demonstrations
• Kinetic art

What's in the Box

• 1 × DC Motor 12GA 3V 30rpm

Tip: A slow geared motor can push hard if it jams, so use end-stop switches to cut the power at the end of travel. Power it from 2 × AA cells through a DRV8833 or L9110S driver, not from a microcontroller pin.
