DC Motor 12GA 3V 500rpm

The DC Motor 12GA 3V 500rpm is a compact 12GA DC gear motor rated for 3 V, with an output speed of 500 rpm, more than 8 turns every second. Its low rated voltage means it runs from just two AA cells, and the fast output suits light mini robots, small fans and spinning models where speed matters more than pulling force.

DC Motor 12GA 3V 500rpm Specifications

• Model: 12GA
• Type: DC gear motor (motor with reduction gearbox)
• Rated voltage: 3 V DC
• Output speed: 500 rpm at 3 V (about 8.3 turns per second)
• Suggested supply: 2 × AA or AAA cells (about 3 V)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 12GA 3V 500rpm Applications

• Fast mini robot cars and racers
• Small fans and spinning toys
• Roller and conveyor models
• Battery-powered science projects

What's in the Box

• 1 × DC Motor 12GA 3V 500rpm

Tip: The L298N driver loses about 2 V inside the chip, leaving little for a 3 V motor, so choose a low-voltage driver such as the DRV8833 or L9110S. With a 40 mm wheel, 500 rpm gives roughly 1 m per second before load.
