DC Motor 12GA 6V 135rpm

The DC Motor 12GA 6V 135rpm is a compact 12GA DC gear motor rated for 6 V, with a reduction gearbox that gives 135 rpm at the output shaft, a little over 2 turns per second. This medium speed is a good balance between pace and pulling force, which makes it well suited to small robot car wheels, robot arms and moving models.

DC Motor 12GA 6V 135rpm Specifications

• Model: 12GA
• Type: DC gear motor (motor with reduction gearbox)
• Rated voltage: 6 V DC
• Output speed: 135 rpm at 6 V (about 2.25 turns per second)
• Suggested supply: 4 × AA or AAA cells (about 6 V)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 12GA 6V 135rpm Applications

• Drive wheels for small robot cars and line followers
• Robot arms, grippers and pan-tilt mechanisms
• Conveyor belt and lift models
• Robotics competitions and STEM classes

What's in the Box

• 1 × DC Motor 12GA 6V 135rpm

Tip: With a 40 mm wheel, 135 rpm gives roughly 0.28 m per second, a speed that is easy to steer for line following. Drive the motor through a TB6612FNG or L9110S driver rather than from an Arduino pin, and give it its own 6 V supply.
