DC Motor 12GA 6V 18rpm

The DC Motor 12GA 6V 18rpm is a compact DC gear motor in the 12GA size, rated for 6 V, with a very slow output speed of 18 rpm, about one turn every 3.3 seconds. The large gear reduction trades speed for torque, so this small motor can turn displays, flaps and dials slowly and smoothly without any extra gearing.

DC Motor 12GA 6V 18rpm Specifications

• Model: 12GA
• Type: DC gear motor (motor with reduction gearbox)
• Rated voltage: 6 V DC
• Output speed: 18 rpm at 6 V (about 1 turn every 3.3 seconds)
• Suggested supply: 4 × AA or AAA cells (about 6 V)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 12GA 6V 18rpm Applications

• Rotating displays and signs
• Sun-tracking and solar panel demonstrations
• Time-lapse camera rotators
• Dials, pointers and clock-like models
• Automatic flaps and small doors

What's in the Box

• 1 × DC Motor 12GA 6V 18rpm

Tip: Slow motors are easy to position with simple timing: at 6 V the shaft turns about a quarter turn in 0.8 seconds, though the speed drops under load. Use a limit switch where exact stops matter, and run the motor from a driver such as the TB6612FNG or L9110S.
