DC Motor 12GA 6V 30rpm

The DC Motor 12GA 6V 30rpm is a compact 12GA DC gear motor rated for 6 V, with a high gear reduction that slows the output shaft to 30 rpm, one turn every 2 seconds. The slow speed gives strong, steady torque for its size, so it is well suited to mechanisms that have to move gently and stop in a controlled way.

DC Motor 12GA 6V 30rpm Specifications

• Model: 12GA
• Type: DC gear motor (motor with reduction gearbox)
• Rated voltage: 6 V DC
• Output speed: 30 rpm at 6 V (1 turn every 2 seconds)
• Suggested supply: 4 × AA or AAA cells (about 6 V)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 12GA 6V 30rpm Applications

• Automatic pet feeders and dispensers
• Slow turntables and rotating displays
• Blinds, flaps and small doors
• Winding and lifting mechanisms in models
• Kinetic art projects

What's in the Box

• 1 × DC Motor 12GA 6V 30rpm

Tip: Because the gearbox multiplies torque, a stalled 30 rpm motor can push hard on its mounts and gears, so use end-stop switches to cut the power at the end of travel. Control it through a motor driver such as the L9110S, not directly from an Arduino pin.
