DC Motor 12GA 6V 320rpm

The DC Motor 12GA 6V 320rpm is a compact DC gear motor in the 12GA size, rated for 6 V with an output speed of 320 rpm, about 5 turns every second. The higher speed suits light, fast builds, while the gearbox still adds torque compared with a bare motor. It is a good match for small robots and moving models powered from a 6 V battery pack.

DC Motor 12GA 6V 320rpm Specifications

• Model: 12GA
• Type: DC gear motor (motor with reduction gearbox)
• Rated voltage: 6 V DC
• Output speed: 320 rpm at 6 V (about 5.3 turns per second)
• Suggested supply: 4 × AA or AAA cells (about 6 V)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 12GA 6V 320rpm Applications

• Fast mini robot cars and line followers
• Small fans, spinners and propeller demos
• Conveyor and roller models
• Arduino and ESP32 motor control lessons

What's in the Box

• 1 × DC Motor 12GA 6V 320rpm

Tip: As a guide, a 40 mm wheel on a 320 rpm shaft covers about 0.67 m per second before load. Use a driver such as the DRV8833 or TB6612FNG for PWM speed control, and solder a 0.1 µF ceramic capacitor across the motor terminals to cut electrical noise.
