DC Motor 12GA 6V 80rpm

The DC Motor 12GA 6V 80rpm is a compact 12GA DC gear motor rated for 6 V, with an output speed of 80 rpm, about 1.3 turns per second. The lower speed means more torque from the gearbox, which helps when a small robot has to climb a ramp, carry a load or move an arm in a controlled way.

DC Motor 12GA 6V 80rpm Specifications

• Model: 12GA
• Type: DC gear motor (motor with reduction gearbox)
• Rated voltage: 6 V DC
• Output speed: 80 rpm at 6 V (about 1.3 turns per second)
• Suggested supply: 4 × AA or AAA cells (about 6 V)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 12GA 6V 80rpm Applications

• Slower, more controlled robot cars
• Robot arms, grippers and lifting mechanisms
• Turntables and rotating platforms
• Arduino and ESP32 projects in STEM classes

What's in the Box

• 1 × DC Motor 12GA 6V 80rpm

Tip: With a 40 mm wheel, 80 rpm gives about 0.17 m per second, slow enough for sensor-based robots to react in time. Use a driver module such as the L9110S or TB6612FNG with a separate 6 V supply, and do not leave the motor stalled for long periods.
