DC Motor 13GB External 12V 6rpm

The DC Motor 13GB External 12V 6rpm is a very slow 12 V DC gear motor that turns its output shaft at 6 rpm, or one full turn every 10 seconds. This External version has an open gear train with exposed gear teeth. With a high gear reduction, it gives gentle, steady rotation and more torque than the faster versions, suited to displays and mechanisms that must move slowly.

DC Motor 13GB External 12V 6rpm Specifications

• Type: DC motor with open reduction gearbox (exposed gear teeth)
• Model: 13GB External
• Rated voltage: 12 V DC
• Output speed: 6 rpm at 12 V (one turn every 10 seconds)
• Direction: reversible by swapping the supply polarity
• Speed control: supply voltage or PWM through a motor driver

DC Motor 13GB External 12V 6rpm Applications

• Slow display turntables and rotating signs
• Solar tracker and planetarium models
• Feeding, dosing and dispensing mechanisms
• Time-lapse panning and slow camera mounts
• Engineering and STEM demonstrations

What's in the Box

• 1 × DC Motor 13GB External, 12 V 6 rpm

Tip: At 6 rpm the shaft moves 36 degrees per second, so short timed pulses give fine position steps. Use a 12 V supply with a relay, MOSFET or L298N driver, and add a cover over the open gears where needed.
