DC Motor 16GA-130 12V 100rpm

The DC Motor 16GA-130 12V 100rpm is a small DC gear motor from the 16GA series, which combines a compact DC motor with a miniature gearbox. It runs from a 12 V supply and turns its output shaft at 100 rpm, and the gear reduction gives it far more torque than a bare motor of the same size. Its small body makes it a good fit for compact robots, actuators and models where a 37 mm gear motor would be too big.

DC Motor 16GA-130 12V 100rpm Specifications

• Model: 16GA-130
• Rated voltage: 12 V DC
• Output speed: 100 rpm
• Gearbox: miniature 16GA series gearbox
• Type: DC gear motor

DC Motor 16GA-130 12V 100rpm Applications

• Small robot cars and line-follower robots
• Compact actuators such as locks, valves and small lifts
• Rotating displays, signs and moving models
• Slow mechanisms in school and STEM projects

What's in the Box

• 1 × DC Motor 16GA-130, 12 V 100 rpm

Tip: Drive the motor through an H-bridge motor driver module such as the L298N, never straight from a microcontroller pin, and check that the driver is rated for 12 V. Avoid stalling the motor against a hard stop for long, as the stall current heats the small motor quickly.
