DC Motor 16GA-130 12V 20rpm

The DC Motor 16GA-130 12V 20rpm is a compact 12 V DC gear motor with a miniature 16GA series gearbox. It turns its output shaft at about 20 rpm, one revolution every three seconds, and the high gear reduction gives strong torque for its small size. It suits slow, controlled movement in devices where a larger gear motor would not fit.

DC Motor 16GA-130 12V 20rpm Specifications

• Model: 16GA-130 gear motor
• Type: DC motor with reduction gearbox
• Rated voltage: 12 V DC
• Output speed: about 20 rpm at 12 V
• Gearbox: miniature 16 mm diameter class (16GA series)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 16GA-130 12V 20rpm Applications

• Rotating displays, signs and turntables
• Valve, lock and flap actuators
• Camera pan and solar tracker mechanisms
• Automation, models and STEM projects

What's in the Box

• 1 × DC Motor 16GA-130 12V 20rpm gear motor

Tip: Use a 12 V supply and a motor driver such as the L298N or TB6612FNG for direction and speed control. Fit limit switches so the motor stops at the end of travel instead of stalling.
