DC Motor 16GA-130 12V 30rpm

The DC Motor 16GA-130 12V 30rpm is a small DC gear motor from the 16GA series, which pairs a compact DC motor with a miniature reduction gearbox. It runs from a 12 V supply and turns its output shaft at about 30 rpm, one revolution every two seconds. The gear reduction gives far more turning force than a bare motor of the same size, which suits slow mechanisms in compact devices.

DC Motor 16GA-130 12V 30rpm Specifications

• Model: 16GA-130 gear motor
• Type: DC motor with reduction gearbox
• Rated voltage: 12 V DC
• Output speed: about 30 rpm at 12 V
• Gearbox: miniature 16 mm diameter class (16GA series)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 16GA-130 12V 30rpm Applications

• Turntables and rotating displays
• Small actuators such as locks and flaps
• Robot grippers and pan mechanisms
• Models and STEM projects

What's in the Box

• 1 × DC Motor 16GA-130 12V 30rpm gear motor

Tip: Drive the motor through an H-bridge driver rated for 12 V, such as the L298N or TB6612FNG, never straight from a microcontroller pin. Avoid stalling it against a hard stop for long, as the small motor heats quickly.
