DC Motor 37GB-545 12V 2rpm

The DC Motor 37GB-545 12V 2rpm is an extremely slow DC gear motor from the 37GB series, a brushed DC motor fitted with a 37 mm reduction gearbox. Powered at 12 V, its output shaft turns at 2 rpm, one full turn every 30 seconds. It is made for very slow, steady motion such as shop window turntables, time-lapse panning, solar tracking and kinetic art.

DC Motor 37GB-545 12V 2rpm Specifications

• Model: 37GB-545
• Type: brushed DC motor with reduction gearbox
• Rated voltage: 12 V DC
• Output speed: 2 rpm at the gearbox shaft at 12 V
• Gearbox: 37 mm diameter (37GB series)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 37GB-545 12V 2rpm Applications

• Shop window turntables and slow rotating displays
• Time-lapse camera panning
• Solar trackers
• Kinetic art and moving models
• Slow dosing and feeding mechanisms

What's in the Box

• 1 × DC Motor 37GB-545, 12 V 2 rpm

Tip: If you need even finer control, slow it further with PWM from the motor driver, and add a limit switch or position sensor for end stops. Use a 12 V supply and an H-bridge driver such as an L298N, never a microcontroller pin directly.
