DC Motor 37GB-545 24V 30rpm

The DC Motor 37GB-545 24V 30rpm is a slow DC gear motor from the 37GB series, made of a DC motor and a 37 mm reduction gearbox. On a 24 V supply its output shaft turns at 30 rpm, and the high gear reduction gives plenty of torque for valve and damper actuators, small lifts, solar trackers and other slow 24 V mechanisms.

DC Motor 37GB-545 24V 30rpm Specifications

• Model: 37GB-545
• Rated voltage: 24 V DC
• Output speed: 30 rpm at the gearbox shaft
• Gearbox: 37 mm diameter (37GB series)
• Type: DC gear motor
• Direction: reversible by swapping the supply polarity

DC Motor 37GB-545 24V 30rpm Applications

• Valve and damper actuators
• Small lifts and winches
• Solar trackers and positioning drives
• Slow turntables
• 24 V automation and control panels

What's in the Box

• 1 × DC Motor 37GB-545, 24 V 30 rpm

Tip: Use an H-bridge motor driver rated for 24 V and above the motor's stall current, such as a BTS7960 module. Because the output is slow and strong, add end-stop switches and use a solid coupling so the mechanism cannot jam.
