DC Motor 37GB-550 12V 350rpm

The DC Motor 37GB-550 12V 350rpm is a DC gear motor from the 37GB series, pairing a DC motor with a 37 mm gearbox. It runs from 12 V and turns its output shaft at 350 rpm, one of the faster speeds in the range, so it suits robot cars and rovers that need to move quickly, as well as belt drives and rotating brushes. The gearbox still gives more torque than a bare motor.

DC Motor 37GB-550 12V 350rpm Specifications

• Model: 37GB-550
• Rated voltage: 12 V DC
• Output speed: 350 rpm at the gearbox shaft
• Gearbox: 37 mm diameter (37GB series)
• Type: DC gear motor
• Direction: reversible by swapping the supply polarity

DC Motor 37GB-550 12V 350rpm Applications

• Fast robot cars and rovers
• Belt and pulley drives
• Rotating brushes and sweepers
• Mixers and stirrers
• 12 V battery-powered machines

What's in the Box

• 1 × DC Motor 37GB-550, 12 V 350 rpm

Tip: Use an H-bridge motor driver rated above the stall current, such as an L298N for light loads or a BTS7960 for heavier robots, and control the speed with PWM. Mount it with a 37GB motor bracket and use a wheel hub or coupling that fits the shaft.
