Fuse Holder 20mm 2 Pin

The Fuse Holder 20mm 2 Pin holds a standard 20 mm cartridge fuse (5 × 20 mm) and has 2 pins for soldering onto a circuit board. With the fuse in a holder instead of soldered in place, a blown fuse can be taken out and replaced in seconds without desoldering, which makes repairs and testing much easier. It is a simple way to add replaceable overcurrent protection to power supplies, chargers and DIY electronics.

Fuse Holder 20mm 2 Pin Specifications

• Fuse size: 5 × 20 mm cartridge fuses (glass or ceramic)
• Pins: 2
• Mounting: through-hole, soldered to a PCB
• Function: holds the fuse so it can be replaced quickly
• Polarity: none

Fuse Holder 20mm 2 Pin Applications

• Power input protection on custom PCBs
• Power supplies, amplifiers, chargers and LED drivers
• Battery, solar and 12 V projects
• Replacing a damaged fuse holder on an existing board

What's in the Box

• 1 × 20 mm 2-pin fuse holder

Tip: Solder the holder to the board first and fit the fuse afterwards, so soldering heat does not reach the fuse. Always disconnect the power before changing a fuse and replace it with one of the same current and voltage rating; 6 × 30 mm fuses will not fit this holder.
