Micro:Bit BBC v2.2

The Micro:Bit BBC v2.2 is version 2.2 of the BBC micro:bit, a pocket-sized programmable computer made for learning to code. It has an LED display, buttons, a touch logo, sensors, a speaker, a microphone and Bluetooth on one small board, and it can be programmed with block coding in Microsoft MakeCode or with Python, so it suits children, teachers and makers alike.

Micro:Bit BBC v2.2 Specifications

• Processor: Nordic nRF52833, Arm Cortex-M4, 64 MHz
• Memory: 512 KB flash, 128 KB RAM
• Display: 5 × 5 red LED matrix (25 LEDs), also used as a light sensor
• Inputs: 2 programmable buttons (A and B) and a touch-sensitive logo
• Sensors: accelerometer, compass (magnetometer), temperature and MEMS microphone
• Sound: built-in speaker
• Wireless: Bluetooth 5.0 Low Energy and 2.4 GHz micro:bit radio
• Edge connector: large rings for pins 0, 1, 2, 3V and GND, plus smaller pins for I2C, SPI and more
• Power: micro USB, or 2 × AAA batteries through the battery connector

Micro:Bit BBC v2.2 Applications

• Coding lessons in primary and secondary schools
• Step counters, compasses and simple games
• Sound-reactive and music projects with the microphone and speaker
• Radio messaging between two or more micro:bits
• Robot cars and sensor kits with micro:bit expansion boards

What's in the Box

• 1 × BBC micro:bit V2.2 board

Tip: Plug the micro:bit into a computer and it appears as a drive called MICROBIT; drag the program file onto it, or flash it straight from the MakeCode or Python editor in a web browser. Use 2 × AAA cells (3 V) for battery power, never a higher voltage.
