PM15S-020-NSF7

The PM15S-020-NSF7 is a micro PM (permanent-magnet, can-stack) stepper motor about 15 mm across. The 020 in the part number means 20 full steps per revolution, so the shaft turns 18° per step, or 9° in half-step mode. It is a handy motor for makers, students and repair technicians who need precise movement in very little space.

PM15S-020-NSF7 Specifications

• Motor type: 2-phase permanent-magnet (PM) stepper motor
• Body diameter: about 15 mm (from the PM15 code)
• Full steps per revolution: 20
• Step angle: 18° full step, 9° in half-step mode
• Variant code: NSF7

PM15S-020-NSF7 Applications

• Tiny linear or rotary actuators
• Camera, lens and optics experiments
• Moving parts in models and small displays
• Replacement in devices that use the same motor

What's in the Box

• 1 × PM15S-020-NSF7 stepper motor

Tip: Use a multimeter to find the two coils before wiring, then connect them to a driver such as the DRV8833 or L293D. If the motor only vibrates, swap the two wires of one coil or slow down the step rate.
