SIM 800L V2.0 5V Wireless GSM GPRS MODULE Quad-Band W/ Antenna Cable Cap

The SIM 800L V2.0 5V Wireless GSM GPRS Module is a SIM800L quad-band GSM/GPRS board that runs from a 5 V supply, which makes it easier to power than the bare SIM800L core board, whose chip needs 3.4–4.4 V. Controlled with AT commands over a serial port, it lets an Arduino, ESP32 or other microcontroller send and receive SMS, make calls and send data over GPRS. An antenna is included, as stated in the title.

SIM 800L V2.0 5V Specifications

• Chip: SIMCom SIM800L
• Network: 2G GSM/GPRS, quad-band 850/900/1800/1900 MHz
• Supply: 5 V (V2.0 board)
• Interface: serial UART (TX/RX), controlled with AT commands
• Functions: SMS, voice calls and GPRS data
• Antenna: included

SIM 800L V2.0 5V Applications

• SMS alerts from alarms, sensors and security systems
• Remote control of relays and pumps by SMS or phone call
• GPS trackers that report their position over GPRS
• IoT data logging where Wi-Fi is not available

What's in the Box

• 1 × SIM800L V2.0 5V GSM GPRS module
• 1 × antenna

Tip: The module draws current peaks of up to about 2 A when it transmits, so power it from a supply that can deliver this, not from the Arduino 5 V pin. It works only on 2G GSM networks, so check that your SIM card and operator still support 2G.
