Stepper Motor 2-Phase 1.8 deg 3.0A 57BYGH115-003

The Stepper Motor 2-Phase 1.8 deg 3.0A (model 57BYGH115-003) is a high-current hybrid stepper motor in the 57 mm (NEMA 23) frame size. With a 1.8° step angle it moves in 200 precise steps per revolution, which makes it a strong choice for CNC routers, laser engravers, linear stages and other machines that need accurate positioning and more torque than smaller NEMA 17 motors provide.

Stepper Motor 2-Phase 1.8 deg 3.0A Specifications

• Model: 57BYGH115-003
• Phases: 2
• Step angle: 1.8° (200 full steps per revolution)
• Rated current: 3.0 A per phase
• Frame size: 57 mm (NEMA 23), as given by the 57 in the model number
• Control: needs an external stepper driver; microstepping is possible with a suitable driver

Stepper Motor 2-Phase 1.8 deg 3.0A Applications

• CNC routers and milling machines
• Laser engravers and cutters
• Linear actuators and lead-screw or belt-driven stages
• Camera sliders, automation rigs and robotics
• Upgrading or repairing machines that use NEMA 23 motors

What's in the Box

• 1 × 57BYGH115-003 stepper motor

Tip: Use a driver rated for at least 3 A per phase, such as a TB6600 or DM542-type driver; small A4988 and DRV8825 boards cannot supply this current. Find the wires of each coil with a multimeter (they show low resistance to each other) and set the driver current limit to 3.0 A or less to keep the motor from overheating.
