Resistor 220 ohm 20W

The Resistor 220 ohm 20W is a high-power fixed resistor with a resistance of 220 Ω and a power rating of 20 W. It can dissipate far more heat than standard 0.25 W or 0.5 W resistors, so it is used where real power must be handled, such as test loads for 24 V and 48 V supplies, discharging large capacitors and limiting current in power circuits.

Resistor 220 ohm 20W Specifications

• Resistance: 220 Ω
• Power rating: 20 W
• Maximum current at full rating: about 0.3 A (I = √(P ÷ R))
• Maximum voltage at full rating: about 66 V across the resistor (V = √(P × R))
• Polarity: none

Resistor 220 ohm 20W Applications

• Dummy loads for testing 12 V, 24 V and 48 V power supplies
• Discharging capacitors in power supplies, inverters and amplifiers
• Bleeder resistors across filter capacitors
• Current and inrush limiting in power circuits
• Electronics labs and repair benches

What's in the Box

• 1 × 220 Ω 20 W resistor

Tip: At high power the resistor gets very hot, so mount it in free air away from wires and plastic parts and do not touch it while in use. For continuous use, keep the load to about half the rating, 10 W, which with 220 Ω means no more than about 47 V across it.
