Resistor 2W 1K ohm

The Resistor 2W 1K ohm is a through-hole fixed resistor with a resistance of 1 kΩ and a power rating of 2 W. Its larger body handles four times the power of a common 0.5 W resistor, so it is a better choice for circuits running at 12 V, 24 V and above, LED loads, discharge and bleeder resistors, and anywhere a small resistor would run hot.

Resistor 2W 1K ohm Specifications

• Resistance: 1 kΩ (1,000 ohms)
• Power rating: 2 W
• Tolerance: ±5%, 4-band colour code (brown, black, red, gold)
• Type: fixed resistor, axial leads, through-hole
• Pack size: 1 piece

Resistor 2W 1K ohm Applications

• Current limiting for LEDs on 12 V and 24 V supplies
• Bleeder resistors for discharging capacitors
• Voltage dividers and dummy loads in power supplies
• Test loads and general-purpose power circuits

What's in the Box

• 1 × 1 kΩ 2 W resistor

Tip: Resistors have no polarity, so they can be fitted either way round. With 1 kΩ, the 2 W limit is reached at about 45 V across the resistor (P = V² / R), and it runs warm near full power, so leave space around it and keep it away from heat-sensitive parts.
