0.28inch 3.5-30V Two Wire DC Voltmeter Green
Part no. 10020739
- Pick up in Msaitbeh, Beirut
- Delivery across Lebanon
- Bulk and education pricing on request
Description
The 0.28inch 3.5-30V Two Wire DC Voltmeter is a small digital panel meter with a green 0.28 inch LED display that shows DC voltage from 3.5 V to 30 V. It needs only two wires because the meter takes its power from the voltage it measures, which makes it very quick to add to battery packs, power supplies, chargers and project boxes.
0.28inch 3.5-30V Two Wire DC Voltmeter Specifications
- Measuring range: 3.5–30 V DC
- Display: 3-digit LED, 0.28 inch digit height
- Display colour: green
- Wiring: 2 wires, power and measurement share the same connection
- Type: DC voltmeter only (no current reading)
0.28inch 3.5-30V Two Wire DC Voltmeter Applications
- Battery voltage monitoring for 12 V and 24 V systems
- Bench and DIY power supply displays
- Solar charging and car battery projects
- Adding a voltage readout to enclosures and control panels
What's in the Box
- 1 × 0.28 inch two-wire DC voltmeter, green display
Tip: Connect the positive wire (usually red) to the voltage you want to measure and the negative wire to ground, and do not reverse them. Because the meter is powered by the measured voltage, it will not read below about 3.5 V; for lower voltages use a three-wire voltmeter with a separate supply.
