Voltage Regulator 7905 TO-220

The Voltage Regulator 7905 TO-220 is a fixed negative linear voltage regulator that gives a steady −5 V output from a more negative input voltage. It is the negative partner of the 7805 and is used wherever a circuit needs a −5 V rail, for example in dual ±5 V supplies for op-amps, audio circuits and analog sensor interfaces. Built-in current limiting and thermal shutdown protect it from overloads.

Voltage Regulator 7905 TO-220 Specifications

• Output voltage: −5 V, fixed
• Output current: up to 1.5 A with a suitable heatsink
• Input voltage: about −7 V to −25 V (−35 V absolute maximum)
• Package: TO-220, 3 pins
• Pinout (front view, left to right): 1 = GND, 2 = input, 3 = output
• Protection: internal current limiting and thermal shutdown

Voltage Regulator 7905 TO-220 Applications

• Negative rail of ±5 V dual power supplies, together with a 7805
• Op-amp, audio and analog circuits that need a negative supply
• Lab and educational power supply projects
• Repairing equipment that uses a −5 V rail

What's in the Box

• 1 × 7905 −5 V voltage regulator, TO-220

Tip: The 7905 pinout differs from the 7805, and its metal tab is connected to the input, not to ground, so insulate it from a grounded heatsink. Fit a 2.2 µF capacitor on the input and a 1 µF capacitor on the output, close to the pins, for stable operation.
