24pin Big 3.1*1.8

The 24pin Big socket is a wide 24-pin DIP IC socket, about 3.1 × 1.8 cm, for integrated circuits with 0.6 in (15.24 mm) row spacing. Solder the socket to your PCB or perfboard and plug the chip into it, so the IC is protected from soldering heat and can be removed or replaced at any time without desoldering.

24pin Big IC Socket Specifications

• Pin count: 24 (2 rows of 12)
• Row spacing: wide, 0.6 in (15.24 mm)
• Pin pitch: 2.54 mm (0.1 in)
• Size: about 3.1 × 1.8 cm
• Mounting: through-hole, solder to a PCB or perfboard

24pin Big IC Socket Applications

• Mounting wide 24-pin DIP chips such as 6116 SRAM and 2716 EPROM memories
• Protecting chips from heat while soldering
• Quick replacement of ICs during repairs
• Swapping or reprogramming chips during development
• Electronics projects, kits and student labs

What's in the Box

• 1 × wide 24-pin DIP IC socket

Tip: Measure the distance between your IC's two rows of pins: 15.24 mm (0.6 in) needs this wide socket, while 7.62 mm (0.3 in) chips need the narrow version. Line up the notch on the socket with the notch on the IC to keep pin 1 in the right place.
