2N2219A

The 2N2219A is a general-purpose NPN silicon transistor in a TO-39 metal can, designed for high-speed switching and amplification at currents up to 800 mA. The metal case can dissipate more heat than a plastic TO-92 package, so it is a good choice for driving relays, lamps, solenoids and small motors, and for audio and RF amplifier stages.

2N2219A Specifications

• Type: NPN bipolar junction transistor (BJT)
• Package: TO-39 metal can, through-hole
• Collector-emitter voltage (VCEO): 40 V
• Collector-base voltage (VCBO): 75 V
• Collector current (IC): up to 800 mA
• Power dissipation: 0.8 W in free air, 3 W with the case at 25 °C
• DC current gain (hFE): 100–300 at 150 mA
• Transition frequency (fT): 300 MHz minimum
• Complementary PNP: 2N2905A

2N2219A Applications

• Driving relays, lamps, solenoids and small motors from logic circuits
• Medium-current switching up to 800 mA
• Audio amplifier and driver stages
• RF and oscillator circuits
• Electronics labs and repair of older equipment

What's in the Box

• 1 × 2N2219A NPN transistor

Tip: On the TO-39 can, the lead next to the small tab is the emitter, followed by the base and then the collector. The metal case is connected to the collector, so keep it from touching other parts, and use a base resistor and a flyback diode when switching coils.
