BC547 Pack 5pcs

The BC547 is a general-purpose NPN bipolar junction transistor for small-signal switching and amplification, and this pack contains 5 pieces. It handles up to 100 mA of collector current and 45 V, which makes it a good choice for driving LEDs, small buzzers and small relays from an Arduino, ESP32 or Raspberry Pi pin, and for audio preamplifiers and sensor circuits.

BC547 Specifications

• Type: NPN bipolar junction transistor (BJT)
• Package: TO-92, through-hole
• Collector-emitter voltage (VCEO): 45 V
• Collector-base voltage (VCBO): 50 V
• Collector current (IC): up to 100 mA
• Power dissipation: 500–625 mW, depending on the maker
• DC current gain (hFE): 110–800, depending on the gain group (A, B or C)
• Transition frequency (fT): about 300 MHz
• Complementary PNP: BC557
• Pack size: 5 pieces

BC547 Applications

• Switching LEDs, small buzzers and small relays from microcontroller pins
• Audio preamplifiers and small-signal amplifiers
• Sensor interfaces, such as LDR and IR detector circuits
• Logic inverters, level shifting and oscillators
• Electronics education and STEM labs

What's in the Box

• 5 × BC547 NPN transistors

Tip: With the flat face towards you and the legs down, the usual BC547 pin order is collector, base, emitter (C-B-E). Use a base resistor of about 1 kΩ to 10 kΩ from a 5 V pin, and keep the load below 100 mA.
