ADK USB Host Shield

The ADK USB Host Shield is an Arduino shield that adds a full-size USB host port to boards such as the Arduino Uno. Based on the MAX3421E USB host controller, it lets your Arduino talk to USB devices such as keyboards, mice, game controllers, Bluetooth dongles and Android phones using the Android Open Accessory (ADK) protocol. It plugs on top of the Arduino and works with the popular USB Host Shield Library 2.0.

ADK USB Host Shield Specifications

• Controller: MAX3421E USB host controller
• USB port: full-size USB Type-A host socket
• USB speed: full speed (12 Mbit/s) and low speed devices
• Interface to Arduino: SPI
• Compatible boards: Arduino Uno and other boards with the Uno shield layout
• Software: USB Host Shield Library 2.0 for the Arduino IDE

ADK USB Host Shield Applications

• Reading USB keyboards, mice and barcode scanners with Arduino
• Controlling robots with PS3, PS4 or Xbox controllers
• Bluetooth projects with a USB Bluetooth dongle
• Android Open Accessory (ADK) projects with an Android phone
• USB serial and MIDI device experiments

What's in the Box

• 1 × USB host shield

Tip: The shield uses the SPI pins plus a chip-select and an interrupt pin (D10 and D9 on most versions), so avoid using those pins for other parts. Some USB devices draw more current than the Arduino 5 V supply can give, so power the board from an external supply when using them.
