Air Pressure Sensor MPX5100AP

The Air Pressure Sensor MPX5100AP is an integrated silicon pressure sensor that measures absolute pressure and gives a ready-to-use analog voltage. Signal conditioning and temperature compensation are built into the chip, so its output can go straight to the analog input of an Arduino or other microcontroller without an extra amplifier. The AP version has a single pressure port for connecting a tube.

Air Pressure Sensor MPX5100AP Specifications

• Pressure type: absolute
• Pressure range: 15–115 kPa
• Supply voltage: 5 V (4.75–5.25 V)
• Output: analog voltage, about 0.2 V to 4.7 V across the range
• Sensitivity: 45 mV/kPa
• Accuracy: ±2.5% of full scale from 0 to 85 °C
• Response time: 1 ms
• Package: 6-pin unibody with one pressure port

Air Pressure Sensor MPX5100AP Applications

• Barometric and absolute pressure measurement
• Pneumatic systems and air pressure monitoring
• Vacuum and suction checks within the sensor range
• Lab experiments on gas laws and pressure
• Pressure data logging with Arduino analog inputs

What's in the Box

• 1 × MPX5100AP pressure sensor

Tip: On the MPX5100, pin 1 (marked by a notch) is Vout, pin 2 is GND and pin 3 is the 5 V supply; pins 4–6 are not connected. Add the decoupling and output filter capacitors shown in the datasheet, and read the output with a 5 V-referenced ADC.
