AMS1117 5V Power Supply Module

The AMS1117 5V Power Supply Module is a small linear regulator board that turns a higher DC input into a steady 5 V output. It is built around the AMS1117-5.0 low-dropout regulator, which can supply up to 1 A, making it a simple way to power Arduino boards, sensors and 5 V modules from a 7.4 V Li-ion pack, a 9 V battery or a 12 V adapter.

AMS1117 5V Power Supply Module Specifications

• Regulator: AMS1117-5.0 low-dropout linear regulator
• Output voltage: 5 V fixed
• Output current: up to 1 A (less without good heat dissipation)
• Dropout voltage: about 1.1 V typical, 1.3 V maximum at 1 A
• Input voltage: about 6.5–12 V recommended (15 V maximum for the regulator)
• Protection: built-in current limiting and thermal shutdown

AMS1117 5V Power Supply Module Applications

• Making a 5 V rail from a 9 V or 12 V supply
• Powering sensors, modules and displays on a breadboard
• Regulated 5 V for battery-powered robots and gadgets
• Low-noise 5 V supply for small analog circuits

What's in the Box

• 1 × AMS1117 5V power supply module

Tip: A linear regulator turns the extra voltage into heat: with 12 V in and 500 mA out it must get rid of about 3.5 W, which is too much for the small chip. For higher currents or large voltage drops, use a buck converter such as the LM2596 instead.
