BC546 Pack 5pcs

The BC546 is an NPN general-purpose silicon transistor in a TO-92 package, sold in a pack of 5. Its 65 V collector-emitter rating is higher than that of the BC547 and BC548, which makes it a good choice for small-signal amplifiers and switching circuits that run from higher supply voltages. It is widely used in Arduino projects, audio preamplifiers and repair work.

BC546 Specifications

• Type: NPN bipolar junction transistor (BJT)
• Collector-emitter voltage (VCEO): 65 V
• Collector-base voltage (VCBO): 80 V
• Collector current (IC): 100 mA continuous
• Power dissipation: 500 mW
• Package: TO-92, through-hole, pinout C-B-E with the flat face towards you
• PNP complement: BC556
• Pack size: 5 pieces

BC546 Applications

• Switching LEDs, buzzers and small relays from Arduino or ESP32 pins
• Audio preamplifiers and microphone amplifiers
• Amplifying weak sensor signals
• Oscillators, timers and logic-level interfacing
• Electronics education and STEM projects

What's in the Box

• 5 × BC546 NPN transistors

Tip: Always use a base resistor, for example 1 kΩ from a 5 V microcontroller pin, and keep the collector current below 100 mA. Add a flyback diode such as the 1N4148 or 1N4007 across any relay coil you switch with it.
