BC557 Pack 5pcs

The BC557 is a general-purpose PNP bipolar transistor in a small TO-92 package, sold here in a pack of 5. It handles up to 100 mA of collector current and 45 V, which makes it a good choice for switching loads on the positive (high) side, small-signal amplifiers and current sources. It is the PNP complement of the popular BC547 NPN transistor.

BC557 Specifications

• Type: PNP bipolar junction transistor (BJT)
• Collector-emitter voltage (VCEO): −45 V
• Collector current (IC): −100 mA max
• Power dissipation: about 500 mW
• DC current gain (hFE): 110 to 800, depending on gain group (A, B or C)
• Package: TO-92, through-hole
• Pinout: collector, base, emitter (flat side facing you, leads down)
• Pack size: 5 pieces

BC557 Applications

• High-side switching of LEDs, small relays and other small loads
• Push-pull output stages together with the BC547
• Audio pre-amplifiers and small-signal amplifiers
• Current mirrors and constant-current sources
• Electronics education and prototyping

What's in the Box

• 5 × BC557 PNP transistors

Tip: Connect the emitter to the positive supply and the load between the collector and ground; pulling the base low through a 1 kΩ to 4.7 kΩ resistor turns it on. When driving it from an Arduino pin, keep the emitter on the same 5 V supply, or the transistor cannot switch fully off.
