Brass Coupler (2-5mm)

The Brass Coupler (2-5mm) is a small rigid shaft coupler with a 2 mm bore on one end and a 5 mm bore on the other. Use it to connect a small motor shaft to a larger drive shaft, axle or rod when the two diameters do not match. Brass is easy to machine and does not rust, which makes it a common choice for RC models, robots and DIY mechanisms.

Brass Coupler (2-5mm) Specifications

• Type: rigid shaft coupler (shaft size adapter)
• Material: brass
• Bore sizes: 2 mm on one end, 5 mm on the other
• Fixing: set (grub) screws clamp each shaft
• Alignment: joins two round shafts on the same axis

Brass Coupler (2-5mm) Applications

• Connecting a 2 mm micro motor shaft to a 5 mm drive shaft or axle
• RC boat, car and aircraft drivetrains
• Robot wheels, arms and small linear mechanisms
• School and university mechanical projects

What's in the Box

• 1 × brass coupler, 2 mm to 5 mm

Tip: Line up the two shafts carefully before tightening the set screws. A rigid coupler cannot absorb misalignment, so any offset will cause vibration and wear. If a shaft has a flat side, tighten the screw onto the flat for a stronger grip.
