Code Cell controller, penny size , ESP32 sensory-controller original , light +motion 17Mah , 20C LIPO, unsoldered

The Code Cell controller is a penny-size ESP32 sensory controller that puts a microcontroller, sensors and battery charging on one tiny round board. This light + motion version includes a light and proximity sensor and a motion sensor, so a project can react to its surroundings and to how it is moved or tilted without extra modules. It is supplied unsoldered, so you only wire the pins you need.

Code Cell controller Specifications

• Microcontroller: ESP32-C3, 32-bit RISC-V, up to 160 MHz
• Wireless: 2.4 GHz Wi-Fi and Bluetooth Low Energy
• Light sensing: on-board ambient light and proximity sensor
• Motion sensing: on-board motion sensor for orientation and movement
• Power: USB-C for programming and power, with built-in LiPo charging
• Battery: small 20C LiPo cell, as listed in the title
• Size: about the size of a coin
• Pins: supplied unsoldered
• Programming: Arduino IDE

Code Cell controller Applications

• Wearables and smart jewellery
• Tiny robots and gesture-controlled gadgets
• Battery-powered Wi-Fi or Bluetooth sensor nodes
• Light-reactive and proximity-triggered projects
• Learning ESP32 programming with built-in sensors

What's in the Box

• 1 × Code Cell controller, light + motion version (unsoldered)
• 1 × 20C LiPo battery (as listed in the title)

Tip: The ESP32-C3 works at 3.3 V, so keep signals on its pins at 3.3 V or below. Check the LiPo battery polarity before connecting it, because reversing it can damage the board.
