HC-06 Bluetooth Bee Slave Module

The HC-06 Bluetooth Bee Slave Module is an HC-06 serial Bluetooth module on a board with the XBee (Bee) footprint. It plugs into XBee sockets, XBee shields and IO expansion boards, and gives an Arduino or other microcontroller a wireless serial link to a phone, tablet or PC without any Bluetooth programming: data sent to its UART simply comes out on the other side.

HC-06 Bluetooth Bee Slave Module Specifications

• Bluetooth module: HC-06, Bluetooth 2.0 + EDR, serial port profile (SPP)
• Role: slave; phones and PCs connect to it
• Form factor: XBee-compatible 20-pin footprint, 2.0 mm pitch
• Interface: UART serial (TX, RX), configurable with AT commands
• Default settings: 9600 baud, name HC-06, pairing PIN 1234
• Operating voltage: 3.3 V

HC-06 Bluetooth Bee Slave Module Applications

• Controlling Arduino robots and cars from an Android app
• Wireless serial monitor for debugging
• Sending sensor data to a phone or PC
• Replacing a serial cable in XBee-shield projects

What's in the Box

• 1 × HC-06 Bluetooth Bee module

Tip: Supply the module with 3.3 V only; an XBee shield or socket normally provides this. Cross the serial lines (module TX to board RX, module RX to board TX). iPhones do not support classic Bluetooth serial links like this, so use an Android phone or a PC.
