LCD1602 without backlight

The LCD1602 without backlight is a 16 × 2 character LCD that shows two lines of 16 characters. With no backlight it uses less power than the backlit version and is easy to read in daylight or a well-lit room. It uses the standard HD44780-compatible controller, so it works with the Arduino LiquidCrystal library straight away.

LCD1602 without backlight Specifications

• Display: 16 characters × 2 lines
• Character format: 5 × 8 dot matrix
• Controller: HD44780-compatible
• Interface: parallel, 4-bit or 8-bit mode
• Supply voltage: 5 V
• Backlight: none, reads by ambient light
• Contrast: adjustable through the V0 pin

LCD1602 without backlight Applications

• Showing sensor readings, menus and messages in Arduino projects
• Low-power, battery-run displays
• Instruments and control panels used in bright places
• Electronics classes on displays and the LiquidCrystal library

What's in the Box

• 1 × LCD1602 display module without backlight

Tip: Connect a 10 kΩ potentiometer to V0 to set the contrast; without it the screen may look blank. In 4-bit mode you only need six Arduino pins (RS, E and D4–D7), with RW tied to ground.
