LM2596 DC-DC Step-down Adjustable voltage regulator with Cable

The LM2596 DC-DC Step-down adjustable voltage regulator lowers a higher DC voltage to the level your project needs, and this version comes with a cable for easy connection. Being a switching (buck) regulator, it wastes far less power as heat than a linear regulator, so it is ideal for running 5 V or 3.3 V boards from 12 V or 24 V supplies.

LM2596 DC-DC Step-down Specifications

• Regulator IC: LM2596 adjustable buck regulator
• Topology: step-down (buck)
• IC input voltage: up to 40 V
• IC output current: up to 3 A
• Output voltage: adjustable from about 1.23 V, always below the input
• Switching frequency: 150 kHz
• Adjustment: on-board potentiometer
• Extras: connection cable included

LM2596 DC-DC Step-down Applications

• Powering Arduino, ESP32 and Raspberry Pi from 12 V or 24 V
• Car and solar battery projects
• Running sensors and modules at 3.3 V or 5 V
• Adjustable bench supply for prototypes

What's in the Box

• 1 × LM2596 step-down regulator module with cable

Tip: Keep the input at least about 1.5 V above the output, and set the output with a multimeter before connecting your board. For loads above about 2 A, add a heatsink or airflow.
