MMA7455 3 axis accelerometer acceleration

The MMA7455 3 axis accelerometer is a digital motion sensor module based on the Freescale (NXP) MMA7455L. It measures acceleration on the X, Y and Z axes in ±2, ±4 or ±8 g ranges and sends the data over I2C or SPI, so it connects easily to an Arduino, ESP32 or Raspberry Pi. Built-in level and pulse detection can flag motion, taps and free fall on two interrupt pins.

MMA7455 3 axis accelerometer Specifications

• Sensor: MMA7455L 3-axis digital accelerometer
• Ranges: ±2 g, ±4 g or ±8 g (8-bit), plus a 10-bit mode at ±8 g
• Interfaces: I2C and SPI
• I2C address: 0x1D
• Chip supply voltage: 2.4–3.6 V
• Interrupts: 2 pins for motion, pulse and free-fall events
• Calibration: offset registers for each axis

MMA7455 3 axis accelerometer Applications

• Tilt sensing and orientation detection
• Tap and shake input for gadgets and games
• Free-fall and impact detection
• Motion logging for robots and vehicles

What's in the Box

• 1 × MMA7455 3-axis accelerometer module

Tip: The MMA7455L is a 3.3 V chip, so check whether your module has a regulator before connecting it to 5 V, and use a level shifter on the I2C lines of a 5 V Arduino if needed. Lay the board flat and store the offset values once to calibrate it.
