Servo Grove

Part no. 10420027

$12.50
In stock
  • Pick up in Msaitbeh, Beirut
  • Delivery across Lebanon
  • Bulk and education pricing on request
Description

The Servo Grove is a micro servo motor fitted with a Grove connector, so it plugs straight into a Grove Base Shield and moves to the angle you set in code. Servos hold a position instead of spinning freely, which makes them a good fit for robot arms, grippers, pan-tilt camera mounts and moving pointers. It is a quick way to add motion to Arduino and Grove projects without extra wiring.

Servo Grove Specifications

  • Operating voltage: 4.8–6.0 V (5 V typical)
  • Torque: 1.5–1.8 kg·cm
  • Speed: 0.12–0.16 s per 60°
  • Control range: 0–180° with the Arduino Servo library
  • Size: 32 × 11.5 × 24 mm
  • Weight: 8.5 g
  • Interface: Grove connector, one PWM signal pin

Servo Grove Applications

  • Robot arms, grippers and walking robots
  • Pan-tilt mounts for cameras and sensors
  • Automatic door locks, flaps and pointers
  • Grove starter kits and STEM classes

What's in the Box

  • 1 × Servo Grove micro servo

Tip: Plug the servo into a digital Grove port and use the Arduino Servo library, for example myservo.write(90) to move it to the centre. If several servos move at once, power them from a separate 5 V supply with a shared ground, because their current peaks can reset the board.
