Servo MG995 12KG

The Servo MG995 12KG is a standard-size servo motor with metal gears, listed with a torque of 12 kg·cm. It turns to a set angle according to a PWM signal, so it is a popular choice for robot arms, RC cars and boats, pan-tilt mounts and other Arduino or ESP32 projects that need more strength than a micro servo.

Servo MG995 12KG Specifications

• Model: MG995
• Torque: 12 kg·cm (as listed)
• Gears: metal
• Size: standard servo size
• Operating voltage: 4.8–7.2 V
• Control signal: PWM, 50 Hz, about 1–2 ms pulse width
• Wires: brown (GND), red (V+), orange (signal)

Servo MG995 12KG Applications

• Robot arms, grippers and walking robots
• Steering for RC cars and control surfaces for RC planes
• Pan-tilt camera mounts
• Automated doors, valves and locks in Arduino projects

What's in the Box

• 1 × MG995 servo motor

Tip: Do not power the MG995 from the Arduino 5 V pin; under load it draws much more current than that pin can supply. Use a separate 5–6 V supply, connect its ground to the Arduino ground, and control the servo with the Arduino Servo library.
