Triple NAND (3 input ) 7410

Part no. 10380901

$0.30
In stock
  • Pick up in Msaitbeh, Beirut
  • Delivery across Lebanon
  • Bulk and education pricing on request
Description

The Triple NAND (3 input ) 7410 is a 74-series logic IC with three independent NAND gates, each with three inputs. A gate's output goes low only when all three of its inputs are high; in every other case the output is high. The 7410 is used to combine control signals, decode states and build other logic functions in digital circuits and electronics labs.

Triple NAND (3 input ) 7410 Specifications

  • Logic function: 3 × 3-input NAND, Y = NOT(A·B·C)
  • Package: 14-pin DIP, through-hole
  • Supply: 5 V, VCC on pin 14 and GND on pin 7
  • Gate 1: inputs on pins 1, 2 and 13, output on pin 12
  • Gate 2: inputs on pins 3, 4 and 5, output on pin 6
  • Gate 3: inputs on pins 9, 10 and 11, output on pin 8

Triple NAND (3 input ) 7410 Applications

  • Detecting when three signals are high at the same time
  • Building AND, OR and NOT functions, since NAND is a universal gate
  • Decoding counter and state-machine outputs
  • Simple set-reset latches using cross-coupled gates
  • Digital logic lab experiments in schools and universities

What's in the Box

  • 1 × 7410 triple 3-input NAND gate IC

Tip: To use a gate as a 2-input NAND, tie the spare input to VCC; to use it as an inverter, join all three inputs together. Do not leave inputs floating, and fit a 100 nF capacitor between pins 14 and 7 close to the chip.
